What is the life expectancy of a transformer? 20, 30, or 40+ years?

Bowers Transformers are designed and manufactured to BSEN60076 which states that liquid-filled distribution and power transformers should have solid insulation to class A, or better, which is suitable for 105°C. It is generally the insulation that determines the life expectancy of a transformer, assuming that no catastrophic failures occur due to external factors.

life expectancy of a transformer report

BSEN60076 Part 7, Clause 6.4, Table 3 states that standard transformer insulation is designed for 180000 hours of service (20.5 years) when working at full load and 98°C hot spot temperature  (110°C for thermally upgraded insulation), as extracted below.


6.4 Insulation life

Reference [7] suggests four different end-of-life criteria, i.e., four different lifetimes for thermally upgraded paper as shown in Table 3.

Table 3 – Normal insulation life of a well-dried, oxygen-free thermally upgraded insulation system at the reference temperature of 110°C
Basis Normal Insulation Life
Hours Years
50% retained tensile strength of insulation 65 000 7.42
25% retained tensile strength of insulation 135 000 15.41
200 retained degree of polymerisation in insulation 150 000 17.12
Interpretation of distribution transformer functional life test data 180 000 20.55

The lifetimes in Table 3 are for reference purposes only since most power transformers will operate at well below full load for most of their actual lifetime. A hot-spot temperature of as little as 6°C below rated values results in half the rated loss of life, the actual lifetime of transformer insulation being several times, for example, 180 000h.”

In the real world, transformers will be working at reduced average loads with ambient temperatures below 20°C and therefore the average hot spot temperature will be well below 98°C, which could greatly increase the 20.5-year life expectancy of a transformer to approaching 40 years.

However, as the quality of the dielectric liquid degrades over time (overheating due to overloads/overvoltages, increased moisture and increased oxygen) this will damage the solid insulation and have a detrimental effect on the life expectancy of a transformer.

Therefore, if the transformer is well maintained and serviced it should have a life expectancy well in excess of 20 years.

The moisture and oxygen levels can be reduced by maintaining the silica gel breather or using a sealed style tank with periodic oil filtration or even an oil change based on liquid sample/DGA data.

If the transformer is well maintained and serviced it could easily approach a working life of 40 years.
